unicable.xml Enigma² Geräte (VU+/ DMM/GigaBlue/Xtrend etc)

Ungelesener Beitragvon techno-com » 11. April 2014 13:55

unicable.xml für Enigma² Geräte (VU+/ DMM/GigaBlue/Xtrend/Opticum/Clarke-Tech/Anadol etc)

Datei entpacken und nach /usr/share/enigma2/ hoch laden, alte Datei dabei ersetzen/überschreiben.

Nach einem Neustart der Box werden nun fast alle auf dem Markt vorhandenen LNBs und Unicable-Multischalter auch im Antennenmenu (Auswahlmenü für SCR dort) angegeben und die IDs/Frequenzen müssen nicht mehr von Hand eingetragen werden.

Liste ist bereits vorbereitet für JESS-Geräte.

<?xml version="1.0" encoding="iso-8859-1"?>
<unicable version="20140510">
<!--
Made by Sat-Shop Heilbronn https://www.satshop-heilbronn.de
structur of tree
unicable (version)
|
|
|
| lnb
| |
| |
| |
| | manufacturer (name)
| | |
| | |
| | | product (name, position, id1-id8, lofl, lofh, loft)
| | |
| | |
| | |
| | | product
| |
| |
| |
| | manufacturer
| | |
| | |
| | | product
| | |
| | |
| | |
| | | product
|


matrix
|
|
|
| manufacturer
| |
| |
| | product
| |
| |
| |
| | product
|
|
|
| manufacturer
| |
| |
| | product
| |
| |
| |
| | product

-->
<lnb>
<manufacturer name="Dur-line">
<product name="UK101" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="UK102" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
<manufacturer name="G-STAR">
<product name="GS-404-L1" scr1="1280" scr2="1382" scr3="1484"/>
<product name="GS-406-L1" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
</manufacturer>
<manufacturer name="GT-SAT">
<product name="GT-S1-2-3SCR4" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
<manufacturer name="Humax">
<product name="150 SCR" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
<manufacturer name="Inverto">
<product name="IDLP-40UNIQD+S" scr1="1680" scr2="1420" scr3="2040" scr4="1210"/>
<product name="IDLB-QUDL-UNI2L-OPP" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
<manufacturer name="Kathrein">
<product name="UAS481" lofl="10200" lofh="10200" scr1="1400" scr2="1516" scr3="1632" scr4="1748"/>
</manufacturer>
<manufacturer name="Kreiling">
<product name="KR1440" scr1="1680" scr2="1420" scr3="2040" scr4="1210"/>
</manufacturer>
<manufacturer name="Radix">
<product name="Unicable LNB" scr1="1680" scr2="1420" scr3="2040" scr4="1210"/>
</manufacturer>
<manufacturer name="Wisi">
<product name="OC 05" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
</lnb>
<matrix>
<manufacturer name="Ankaro">
<product name="UCS 51440" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 51820" scr1="1400" scr2="1632" scr3="1284" scr4="1516" scr5="1864" scr6="2096" scr7="1748" scr8="1980"/>
<product name="UCS 51840" scr1="1400" scr2="1632" scr3="1284" scr4="1516" scr5="1864" scr6="2096" scr7="1748" scr8="1980"/>
<product name="UCS 52240" scr1="1400" scr2="1632"/>
<product name="UCS 52420" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 52440" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 91440" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 91820" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516" scr5="1864" scr6="2096" scr7="1748" scr8="1980"/>
<product name="UCS 91840" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516" scr5="1864" scr6="2096" scr7="1748" scr8="1980"/>
<product name="UCS 92240" positions="2" scr1="1400" scr2="1632"/>
<product name="UCS 92420" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 92440" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
</manufacturer>
<manufacturer name="DCT Delta">
<product name="SUM518" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="SUM918" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="SUM928" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
</manufacturer>
<manufacturer name="Dur-Line">
<product name="UCP2" scr1="1400" scr2="1516"/>
<product name="UCP3" scr1="1280" scr2="1382" scr3="1484"/>
<product name="VDU518NT" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="VDU543NT" scr1="1280" scr2="1382" scr3="1484"/>
<product name="VDU563NT" scr1="1280" scr2="1382" scr3="1484"/>
<product name="VDU583NT" scr1="1280" scr2="1382" scr3="1484"/>
<product name="VDU586NT" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="VDU983NT" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="DCR 5-2-4" scr1="1280" scr2="1382" scr3="1484" scr4="1586"/>
<product name="DCR 5-1-8" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790" scr7="1892" scr8="1994"/>
<product name="UCP18" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
</manufacturer>
<manufacturer name="G-STAR">
<product name="GS-506-S1" scr1="1280" scr2="1382" scr3="1484"/>
<product name="GS-516-S1" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
</manufacturer>
<manufacturer name="Inverto">
<product name="IDLP-UST1O1-CUO1O-4PP" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="IDLP-UST11O-CUO1O-8PP" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="IDLP-USS200-CUO10-8PP" positions="2" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
</manufacturer>
<manufacturer name="JULTEC">
<product name="JRS0504-2" scr1="1280" scr2="1382"/>
<product name="JRS0502-2+4T" scr1="1280" scr2="1382"/>
<product name="JRS0904-2" position="2" scr1="1280" scr2="1382"/>
<product name="JRS0902-2+4T" position="2" scr1="1280" scr2="1382"/>
<product name="JPS0501-8" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="JPS0502-3" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0502-6" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS0504-3" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0504-6" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS0506-3" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0508-3" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0901-6" positions="2" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS0902-3" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0902-6" positions="2" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS0904-3" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0906-3" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0908-3" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS1702-6" positions="4" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS1704-3" positions="4" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS1704-6" positions="4" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS1706-3" positions="4" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS1708-3" positions="4" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0501-12" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="JPS0901-12" positions="2" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="JPS0902-12" positions="2" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="JPS1701-12" positions="4" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="JPS1702-12" positions="4" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
</manufacturer>
<manufacturer name="Kathrein">
<product name="EXR501" scr1="1400" scr2="1516" scr3="1632" scr4="1748"/>
<product name="EXR551" scr1="1400" scr2="1516" scr3="1632" scr4="1748"/>
<product name="EXR552" scr1="1400" scr2="1516"/>
<product name="EXR1541" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR1542" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR1581" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="EXR1942" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR1981" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="EXR2541" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR2542" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR2581" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="EXR2942" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR2981" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="EXU908" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
</manufacturer>
<manufacturer name="ROTEK">
<product name="EKL2/1" scr1="1400" scr2="1516"/>
<product name="EKL2/1E" scr3="1632" scr4="1748"/>
</manufacturer>
<manufacturer name="Smart">
<product name="DPA 51" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="DPA 524 L" scr1="1280" scr2="1382" scr3="1484" scr4="1586"/>
</manufacturer>
<manufacturer name="Spaun">
<product name="SUS 212" scr1="1076" scr2="1178"/>
<product name="SUS 4441 F" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="SUS 5541 F-NFA" scr1="0974" scr2="1076" scr3="1178" scr4="1280"/>
<product name="SUS 5581 F-NFA" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688"/>
<product name="SUS 5581 F-NFA" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688"/>
<product name="SUS 5581 F-NFA" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688"/>
<product name="SUS 5581 NF 1x8" scr1="1068" scr2="1284" scr3="1400" scr4="1516" scr5="1632" scr6="1748" scr7="1864" scr8="1980"/>
<product name="SUS 5581 NF 3x3 1" scr1="1068" scr2="1284" scr3="1400"/>
<product name="SUS 5581 NF 3x3 1" scr1="1516" scr2="1632" scr3="1748"/>
<product name="SUS 5581 NF 3x3 1" scr1="1864" scr2="1980" scr3="2096"/>
<product name="SUS 5581 NF Leg 1x8" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688"/>
<product name="SUS 5581 NF Leg 3x3 1" scr1="0974" scr2="1076" scr3="1178"/>
<product name="SUS 5581 NF Leg 3x3 1" scr1="1280" scr2="1382" scr3="1484"/>
<product name="SUS 5581 NF Leg 3x3 1" scr1="1586" scr2="1688" scr3="1790"/>
</manufacturer>
<manufacturer name="Technisat">
<product name="MiniRouter 2/1x2" scr1="1284" scr2="1400"/>
<product name="TechniRouter 5/1x8" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="TechniRouter 9/1x8" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="TechniRouter 5/2x4" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="TechniRouter 9/2x4" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
</manufacturer>
<manufacturer name="Telstar">
<product name="SCR 5/1x8" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="SCR 9/1x8" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="SCR 5/2x4" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="SCR 9/2x4" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
</manufacturer>
<manufacturer name="Wisi">
<product name="DY 64 1810" scr1="1178" scr2="1280" scr3="1382" scr4="1484" scr5="1586" scr6="1688" scr7="1790" scr8="1892"/>
<product name="DY 64 2410" scr1="1178" scr2="1280" scr3="1382" scr4="1484"/>
<product name="DY 68 1810" positions="2" scr1="1178" scr2="1280" scr3="1382" scr4="1484" scr5="1586" scr6="1688" scr7="1790" scr8="1892"/>
<product name="DY 68 2410" positions="2" scr1="1178" scr2="1280" scr3="1382" scr4="1484"/>
</manufacturer>
</matrix>
</unicable>



Verwendung auf eigene Gefahr, die alte unicable.xml sollte auf jeden Fall vorher gesichert werden
Dateianhänge
unicable.rar
unicable.xml für Enigma² Geräte (VU+/ DMM/GigaBlue/Xtrend/Opticum/Clarke-Tech etc)
(1.63 KiB) 547-mal heruntergeladen


Vielleicht sind wir nicht günstiger als ein Discounter oder reiner Online-Kartonschieber, aber sicherlich besser !
Normkonforme Beratung und Bau sind bei uns selbstverständlich.
Sat-Shop Heilbronn Kunden können sich auch nach dem Kauf auf unseren besten Service verlassen
Hier im Forum wird kein After-Sales-Support für Fremdkäufe geleistet !! Wenden Sie sich dazu an ihren Verkäufer ......

Tristan Uhde / Satanlagen Onlineshop / SAT-Shop Heilbronn
https://www.satshop-heilbronn.de (SSL) / SAT-Onlineforum https://www.satanlagenforum.de (SSL)
Tel ------ (Fragen gehören ins Forum ! Den nur hier können sie richtig bearbeitet werden, auch was hier noch nicht von A-Z genau schon erklärt/behandelt ist ) .. Dieser Hinweis weil täglich dutzende Fragen per Email oder per PM über das Forum rein kommen die noch dazu inhaltlich nicht das intus haben das man etwas dazu sagen könnte.

Wichtiger Hinweis: Zuständigkeiten verantwortliche Elektrofachkraft (VEFK) und Blitzschutzfachkräfte
Informieren Sie sich dort über Folgen und Auswirkungen von Eigenleistung und lassen Sie selbst durchgeführte Installationen von entsprechender Stelle prüfen und abnehmen. Dafür sind VOR ORT spezielle und qualifizierte Blitzschutz-Fachkräfte notwendig, Ferndiagnosen für Blitzschutz/Erdung können hier NICHT durchgeführt werden ("wie kann ICH das machen ..." oder ähnlich bringt da nichts).

Diese Signatur wächst von Woche zu Woche und enthält immer mehr grundlegende Inhalte die bitte berücksichtigt werden sollten bei bzw. VOR Anfragen !
100% beantwortet werden können nur Anfragen die auch alle relevanten Teile beinhalten die man benötigt für eine Antwort (genaue Beschreibungen/ Angabe von Herstellern/Typen für vorhandenes Material etc.). Bitte vermeiden Sie Aussagen wie "habe viel gelesen, aber ..." ohne Nennung von dem was Sie gelesen haben - den nur dann kann man auch darauf eingehen was event. unklar ist/war.

Bitte unbedingt vor einem Post lesen => Boardregeln / Datenschutz
Wir erteilen hier keine Rechtsberatung, unsere Hinweise sind nach bestem Wissen und bedürfen einer entsprechenden juristischen/technischen weiteren Beratung.

Benutzeravatar
techno-com
Site Admin
Beiträge: 19741
Registriert: 17. November 2005 09:32
Wohnort: 74076 Heilbronn
Hat sich bedankt: 413 Mal
Danksagung erhalten: 479 Mal
Kontaktdaten:

Re: unicable.xml Enigma² Geräte (VU+/ DMM/GigaBlue/Xtrend et

Ungelesener Beitragvon techno-com » 6. April 2015 10:03

Update der Datei "unicable.xml" (hier in der Anlage gepackt als .rar)

Update schon im OpenATV Update eingeflossen, klick

<?xml version="1.0" encoding="iso-8859-1"?>
<unicable version="20150406">
<!--
Made by Sat-Shop Heilbronn www.satshop-heilbronn.de
structur of tree
unicable (version)
|
|\
| \
| lnb
| |
| |\
| | \
| | manufacturer (name)
| | |\
| | | \
| | | product (name, position, id1-id8, lofl, lofh, loft)
| | |
| | |\
| | | \
| | | product
| |
| |\
| | \
| | manufacturer
| | |\
| | | \
| | | product
| | |
| | |\
| | | \
| | | product
|
\
\
matrix
|
|\
| \
| manufacturer
| |\
| | \
| | product
| |
| |\
| | \
| | product
|
|\
| \
| manufacturer
| |\
| | \
| | product
| |
| |\
| | \
| | product
-->
<lnb>
<manufacturer name="DUR-line">
<product name="UK101" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="UK102" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
<manufacturer name="G-STAR">
<product name="GS-404-L1" scr1="1280" scr2="1382" scr3="1484"/>
<product name="GS-406-L1" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
</manufacturer>
<manufacturer name="GT-SAT">
<product name="GT-S1-2-3SCR4" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="dLNB1 DHello" scr1="0975" scr2="1025" scr3="1075" scr4="1125" scr5="1175" scr6="1225" scr7="1275" scr8="1325" scr9="1375" scr10="1425" scr11="1475" scr12="1525"/>
<product name="dLNB2 DHello" scr13="1575" scr14="1625" scr15="1725" scr16="1725" scr17="1775" scr18="1825" scr19="1875" scr20="1925" scr21="1975" scr22="2025" scr23="2075" scr24="2125"/>
</manufacturer>
<manufacturer name="Humax">
<product name="150 SCR" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
<manufacturer name="Inverto">
<product name="IDLP-40UNIQD+S" scr1="1680" scr2="1420" scr3="2040" scr4="1210"/>
<product name="IDLB-QUDL-UNI2L-OPP" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
<manufacturer name="Kathrein">
<product name="UAS481" lofl="10200" lofh="10200" scr1="1400" scr2="1516" scr3="1632" scr4="1748"/>
</manufacturer>
<manufacturer name="Kreiling">
<product name="KR1440" scr1="1680" scr2="1420" scr3="2040" scr4="1210"/>
</manufacturer>
<manufacturer name="Radix">
<product name="Unicable LNB" scr1="1680" scr2="1420" scr3="2040" scr4="1210"/>
</manufacturer>
<manufacturer name="Wisi">
<product name="OC 05" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
</lnb>
<matrix>
<manufacturer name="Ankaro">
<product name="UCS 51440" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 51820" scr1="1400" scr2="1632" scr3="1284" scr4="1516" scr5="1864" scr6="2096" scr7="1748" scr8="1980"/>
<product name="UCS 51840" scr1="1400" scr2="1632" scr3="1284" scr4="1516" scr5="1864" scr6="2096" scr7="1748" scr8="1980"/>
<product name="UCS 52240" scr1="1400" scr2="1632"/>
<product name="UCS 52420" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 52440" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 91440" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 91820" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516" scr5="1864" scr6="2096" scr7="1748" scr8="1980"/>
<product name="UCS 91840" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516" scr5="1864" scr6="2096" scr7="1748" scr8="1980"/>
<product name="UCS 92240" positions="2" scr1="1400" scr2="1632"/>
<product name="UCS 92420" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 92440" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
</manufacturer>
<manufacturer name="DCT Delta">
<product name="SUM518" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="SUM918" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="SUM928" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
</manufacturer>
<manufacturer name="Dura-Sat">
<product name="UCP2" scr1="1400" scr2="1516"/>
<product name="UCP3" scr1="1280" scr2="1382" scr3="1484"/>
<product name="UCP20" scr1="1210" scr2="1420"/>
<product name="UCP30" scr1="1210" scr2="1420" scr3="1680"/>
<product name="DCR 5-1-8" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790" scr7="1892" scr8="1994"/>
<product name="DCR 5-2-4" scr1="1280" scr2="1382" scr3="1484" scr4="1586"/>
<product name="VDU518NT" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="VDU543NT" scr1="1280" scr2="1382" scr3="1484"/>
<product name="VDU563NT" scr1="1280" scr2="1382" scr3="1484"/>
<product name="VDU583NT" scr1="1280" scr2="1382" scr3="1484"/>
<product name="VDU586NT" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="VDU983NT" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="UCP18" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
</manufacturer>
<manufacturer name="G-STAR">
<product name="GS-506-S1" scr1="1280" scr2="1382" scr3="1484"/>
<product name="GS-516-S1" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
</manufacturer>
<manufacturer name="Inverto">
<product name="IDLP-UST1O1-CUO1O-4PP" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="IDLP-UST11O-CUO1O-8PP" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="IDLP-UST112-CUO1O-8PP" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="IDLP-USS200-CUO10-8PP" positions="2" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
</manufacturer>
<manufacturer name="JULTEC">
<product name="JRS0504-2" scr1="1280" scr2="1382"/>
<product name="JRS0502-2+4T" scr1="1280" scr2="1382"/>
<product name="JRS0904-2" position="2" scr1="1280" scr2="1382"/>
<product name="JRS0902-2+4T" position="2" scr1="1280" scr2="1382"/>
<product name="JPS0501-8" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="JPS0501-12" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="JPS0502-3" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0502-6" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS0504-3" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0504-6" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS0506-3" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0508-3" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0901-6" positions="2" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS0901-12" positions="2" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="JPS0902-12" positions="2" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="JPS0902-3" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0902-6" positions="2" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS0904-3" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0906-3" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0908-3" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS1701-12" positions="4" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="JPS1702-12" positions="4" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="JPS1702-6" positions="4" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS1704-3" positions="4" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS1704-6" positions="4" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS1706-3" positions="4" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS1708-3" positions="4" scr1="1280" scr2="1382" scr3="1484"/>
</manufacturer>
<manufacturer name="Kathrein">
<product name="EXR159" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790"/>
<product name="EXR1512" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="EXR1541" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR1542" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR1581" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="EXR1942" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR1981" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="EXR2541" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR2542" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR2581" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="EXR2942" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR2981" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="EXR501" scr1="1400" scr2="1516" scr3="1632" scr4="1748"/>
<product name="EXR551" scr1="1400" scr2="1516" scr3="1632" scr4="1748"/>
<product name="EXR552" scr1="1400" scr2="1516"/>
<product name="EXU908" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
</manufacturer>
<manufacturer name="ROTEK">
<product name="EKL2/1" scr1="1400" scr2="1516"/>
<product name="EKL2/1E" scr3="1632" scr4="1748"/>
</manufacturer>
<manufacturer name="Smart">
<product name="DPA 51" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="DPA 524 L" scr1="1280" scr2="1382" scr3="1484" scr4="1586"/>
</manufacturer>
<manufacturer name="Spaun">
<product name="SUS 212" scr1="1076" scr2="1178"/>
<product name="SUS 21 F" scr1="1076" scr2="1178"/>
<product name="SUS 21 FI" scr1="1210" scr2="1420"/>
<product name="SUS 4441 F" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="SUS 5541 F-NFA" scr1="0974" scr2="1076" scr3="1178" scr4="1280"/>
<product name="SUS 5581 F-NFA" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688"/>
<product name="SUS 5581 F-NFA" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688"/>
<product name="SUS 5581 F-NFA" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688"/>
<product name="SUS 5581 NF 1x8" scr1="1068" scr2="1284" scr3="1400" scr4="1516" scr5="1632" scr6="1748" scr7="1864" scr8="1980"/>
<product name="SUS 5581 NF 3x3 1" scr1="1068" scr2="1284" scr3="1400"/>
<product name="SUS 5581 NF 3x3 1" scr1="1516" scr2="1632" scr3="1748"/>
<product name="SUS 5581 NF 3x3 1" scr1="1864" scr2="1980" scr3="2096"/>
<product name="SUS 5581 NF Leg 1x8" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688"/>
<product name="SUS 5581 NF Leg 3x3 1" scr1="0974" scr2="1076" scr3="1178"/>
<product name="SUS 5581 NF Leg 3x3 1" scr1="1280" scr2="1382" scr3="1484"/>
<product name="SUS 5581 NF Leg 3x3 1" scr1="1586" scr2="1688" scr3="1790"/>
</manufacturer>
<manufacturer name="Technisat">
<product name="MiniRouter 2/1x2" scr1="1284" scr2="1400"/>
<product name="TechniRouter 5/1x4" scr1="1210 scr2="1420" scr3="1680" scr4="2040"/>
<product name="TechniRouter 5/1x8" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="TechniRouter 9/1x8" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="TechniRouter 5/2x4" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="TechniRouter 9/2x4" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
</manufacturer>
<manufacturer name="Telstar">
<product name="SCR 5/1x8" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="SCR 9/1x8" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="SCR 5/2x4" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="SCR 9/2x4" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
</manufacturer>
<manufacturer name="Wisi">
<product name="DY 64 1810" scr1="1178" scr2="1280" scr3="1382" scr4="1484" scr5="1586" scr6="1688" scr7="1790" scr8="1892"/>
<product name="DY 64 2410" scr1="1178" scr2="1280" scr3="1382" scr4="1484"/>
<product name="DY 68 1810" positions="2" scr1="1178" scr2="1280" scr3="1382" scr4="1484" scr5="1586" scr6="1688" scr7="1790" scr8="1892"/>
<product name="DY 68 2410" positions="2" scr1="1178" scr2="1280" scr3="1382" scr4="1484"/>
</manufacturer>
</matrix>
</unicable>
Dateianhänge
unicable.rar
unicable.xml für Enigma² Geräte (VU+/ DMM/GigaBlue/Xtrend/Opticum/Clarke-Tech/AX-Technologies etc)
(1.68 KiB) 132-mal heruntergeladen
Vielleicht sind wir nicht günstiger als ein Discounter oder reiner Online-Kartonschieber, aber sicherlich besser !
Normkonforme Beratung und Bau sind bei uns selbstverständlich.
Sat-Shop Heilbronn Kunden können sich auch nach dem Kauf auf unseren besten Service verlassen
Hier im Forum wird kein After-Sales-Support für Fremdkäufe geleistet !! Wenden Sie sich dazu an ihren Verkäufer ......

Tristan Uhde / Satanlagen Onlineshop / SAT-Shop Heilbronn
https://www.satshop-heilbronn.de (SSL) / SAT-Onlineforum https://www.satanlagenforum.de (SSL)
Tel ------ (Fragen gehören ins Forum ! Den nur hier können sie richtig bearbeitet werden, auch was hier noch nicht von A-Z genau schon erklärt/behandelt ist ) .. Dieser Hinweis weil täglich dutzende Fragen per Email oder per PM über das Forum rein kommen die noch dazu inhaltlich nicht das intus haben das man etwas dazu sagen könnte.

Wichtiger Hinweis: Zuständigkeiten verantwortliche Elektrofachkraft (VEFK) und Blitzschutzfachkräfte
Informieren Sie sich dort über Folgen und Auswirkungen von Eigenleistung und lassen Sie selbst durchgeführte Installationen von entsprechender Stelle prüfen und abnehmen. Dafür sind VOR ORT spezielle und qualifizierte Blitzschutz-Fachkräfte notwendig, Ferndiagnosen für Blitzschutz/Erdung können hier NICHT durchgeführt werden ("wie kann ICH das machen ..." oder ähnlich bringt da nichts).

Diese Signatur wächst von Woche zu Woche und enthält immer mehr grundlegende Inhalte die bitte berücksichtigt werden sollten bei bzw. VOR Anfragen !
100% beantwortet werden können nur Anfragen die auch alle relevanten Teile beinhalten die man benötigt für eine Antwort (genaue Beschreibungen/ Angabe von Herstellern/Typen für vorhandenes Material etc.). Bitte vermeiden Sie Aussagen wie "habe viel gelesen, aber ..." ohne Nennung von dem was Sie gelesen haben - den nur dann kann man auch darauf eingehen was event. unklar ist/war.

Bitte unbedingt vor einem Post lesen => Boardregeln / Datenschutz
Wir erteilen hier keine Rechtsberatung, unsere Hinweise sind nach bestem Wissen und bedürfen einer entsprechenden juristischen/technischen weiteren Beratung.

Benutzeravatar
techno-com
Site Admin
Beiträge: 19741
Registriert: 17. November 2005 09:32
Wohnort: 74076 Heilbronn
Hat sich bedankt: 413 Mal
Danksagung erhalten: 479 Mal
Kontaktdaten:

Re: unicable.xml Enigma² Geräte (VU+/ DMM/GigaBlue/Xtrend et

Ungelesener Beitragvon techno-com » 16. April 2015 15:46

Update !!

Jetzt mit JESS (EN50607) Unterstützung !
JESS (EN50607) auf Linux-Enigma² Geräten (Dreambox, VU+...)


<?xml version="1.0" encoding="iso-8859-1"?>
<unicable version="20150416">
<!--
Made by Sat-Shop Heilbronn www.satshop-heilbronn.de
Jetzt mit JESS (EN50607) Unterstützung !! Danke an den User "adenin" dafür !!
structur of tree
unicable (version)
|
|\
| \
| lnb
| |
| |\
| | \
| | manufacturer (name)
| | |\
| | | \
| | | product (name, position, id1-id8, lofl, lofh, loft)
| | |
| | |\
| | | \
| | | product
| |
| |\
| | \
| | manufacturer
| | |\
| | | \
| | | product
| | |
| | |\
| | | \
| | | product
|
\
\
matrix
|
|\
| \
| manufacturer
| |\
| | \
| | product
| |
| |\
| | \
| | product
|
|\
| \
| manufacturer
| |\
| | \
| | product
| |
| |\
| | \
| | product
-->
<lnb>
<manufacturer name="DUR-line">
<product name="UK101" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="UK102" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
<manufacturer name="G-STAR">
<product name="GS-404-L1" scr1="1280" scr2="1382" scr3="1484"/>
<product name="GS-406-L1" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
</manufacturer>
<manufacturer name="GT-SAT">
<product name="GT-S1-2-3SCR4" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="dLNB1 DHello" format="JESS" scr1="0975" scr2="1025" scr3="1075" scr4="1125" scr5="1175" scr6="1225" scr7="1275" scr8="1325" scr9="1375" scr10="1425" scr11="1475" scr12="1525"/>
<product name="dLNB2 DHello" format="JESS" scr13="1575" scr14="1625" scr15="1725" scr16="1725" scr17="1775" scr18="1825" scr19="1875" scr20="1925" scr21="1975" scr22="2025" scr23="2075" scr24="2125"/>
</manufacturer>
<manufacturer name="Humax">
<product name="150 SCR" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
<manufacturer name="Inverto">
<product name="IDLP-40UNIQD+S" scr1="1680" scr2="1420" scr3="2040" scr4="1210"/>
<product name="IDLB-QUDL-UNI2L-OPP" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
<manufacturer name="Kathrein">
<product name="UAS481" lofl="10200" lofh="10200" scr1="1400" scr2="1516" scr3="1632" scr4="1748"/>
</manufacturer>
<manufacturer name="Kreiling">
<product name="KR1440" scr1="1680" scr2="1420" scr3="2040" scr4="1210"/>
</manufacturer>
<manufacturer name="Radix">
<product name="Unicable LNB" scr1="1680" scr2="1420" scr3="2040" scr4="1210"/>
</manufacturer>
<manufacturer name="Wisi">
<product name="OC 05" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
</lnb>
<matrix>
<manufacturer name="Ankaro">
<product name="UCS 51440" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 51820" scr1="1400" scr2="1632" scr3="1284" scr4="1516" scr5="1864" scr6="2096" scr7="1748" scr8="1980"/>
<product name="UCS 51840" scr1="1400" scr2="1632" scr3="1284" scr4="1516" scr5="1864" scr6="2096" scr7="1748" scr8="1980"/>
<product name="UCS 52240" scr1="1400" scr2="1632"/>
<product name="UCS 52420" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 52440" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 91440" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 91820" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516" scr5="1864" scr6="2096" scr7="1748" scr8="1980"/>
<product name="UCS 91840" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516" scr5="1864" scr6="2096" scr7="1748" scr8="1980"/>
<product name="UCS 92240" positions="2" scr1="1400" scr2="1632"/>
<product name="UCS 92420" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 92440" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
</manufacturer>
<manufacturer name="DCT Delta">
<product name="SUM518" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="SUM918" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="SUM928" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
</manufacturer>
<manufacturer name="Dura-Sat">
<product name="UCP2" scr1="1400" scr2="1516"/>
<product name="UCP3" scr1="1280" scr2="1382" scr3="1484"/>
<product name="UCP20" scr1="1210" scr2="1420"/>
<product name="UCP30" scr1="1210" scr2="1420" scr3="1680"/>
<product name="DCR 5-1-8" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790" scr7="1892" scr8="1994"/>
<product name="DCR 5-2-4" scr1="1280" scr2="1382" scr3="1484" scr4="1586"/>
<product name="VDU518NT" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="VDU543NT" scr1="1280" scr2="1382" scr3="1484"/>
<product name="VDU563NT" scr1="1280" scr2="1382" scr3="1484"/>
<product name="VDU583NT" scr1="1280" scr2="1382" scr3="1484"/>
<product name="VDU586NT" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="VDU983NT" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="UCP18" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
</manufacturer>
<manufacturer name="G-STAR">
<product name="GS-506-S1" scr1="1280" scr2="1382" scr3="1484"/>
<product name="GS-516-S1" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
</manufacturer>
<manufacturer name="Inverto">
<product name="IDLP-UST1O1-CUO1O-4PP" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="IDLP-UST11O-CUO1O-8PP" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="IDLP-UST112-CUO1O-8PP" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="IDLP-USS200-CUO10-8PP" positions="2" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
</manufacturer>
<manufacturer name="JULTEC">
<product name="JRS0504-2" scr1="1280" scr2="1382"/>
<product name="JRS0502-2+4T" scr1="1280" scr2="1382"/>
<product name="JRS0904-2" position="2" scr1="1280" scr2="1382"/>
<product name="JRS0902-2+4T" position="2" scr1="1280" scr2="1382"/>
<product name="JPS0501-8" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="JPS0501-12" format="JESS" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="JPS0502-3" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0502-6" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS0504-3" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0504-6" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS0506-3" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0508-3" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0901-6" positions="2" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS0901-12" format="JESS" positions="2" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="JPS0902-12" format="JESS" positions="2" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="JPS0902-3" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0902-6" positions="2" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS0904-3" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0906-3" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0908-3" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS1701-12" format="JESS" positions="4" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="JPS1702-12" format="JESS" positions="4" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="JPS1702-6" format="JESS" positions="4" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS1704-3" format="JESS" positions="4" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS1704-6" format="JESS" positions="4" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS1706-3" format="JESS" positions="4" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS1708-3" format="JESS" positions="4" scr1="1280" scr2="1382" scr3="1484"/>
</manufacturer>
<manufacturer name="Kathrein">
<product name="EXR159" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790"/>
<product name="EXR1512" format="JESS" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="EXR1541" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR1542" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR1581" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="EXR1942" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR1981" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="EXR2541" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR2542" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR2581" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="EXR2942" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR2981" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="EXR501" scr1="1400" scr2="1516" scr3="1632" scr4="1748"/>
<product name="EXR551" scr1="1400" scr2="1516" scr3="1632" scr4="1748"/>
<product name="EXR552" scr1="1400" scr2="1516"/>
<product name="EXU908" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
</manufacturer>
<manufacturer name="ROTEK">
<product name="EKL2/1" scr1="1400" scr2="1516"/>
<product name="EKL2/1E" scr3="1632" scr4="1748"/>
</manufacturer>
<manufacturer name="Smart">
<product name="DPA 51" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="DPA 524 L" scr1="1280" scr2="1382" scr3="1484" scr4="1586"/>
</manufacturer>
<manufacturer name="Spaun">
<product name="SUS 212" scr1="1076" scr2="1178"/>
<product name="SUS 21 F" scr1="1076" scr2="1178"/>
<product name="SUS 21 FI" scr1="1210" scr2="1420"/>
<product name="SUS 4441 F" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="SUS 5541 F-NFA" scr1="0974" scr2="1076" scr3="1178" scr4="1280"/>
<product name="SUS 5581 F-NFA" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688"/>
<product name="SUS 5581 F-NFA" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688"/>
<product name="SUS 5581 F-NFA" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688"/>
<product name="SUS 5581 NF 1x8" scr1="1068" scr2="1284" scr3="1400" scr4="1516" scr5="1632" scr6="1748" scr7="1864" scr8="1980"/>
<product name="SUS 5581 NF 3x3 1" scr1="1068" scr2="1284" scr3="1400"/>
<product name="SUS 5581 NF 3x3 1" scr1="1516" scr2="1632" scr3="1748"/>
<product name="SUS 5581 NF 3x3 1" scr1="1864" scr2="1980" scr3="2096"/>
<product name="SUS 5581 NF Leg 1x8" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688"/>
<product name="SUS 5581 NF Leg 3x3 1" scr1="0974" scr2="1076" scr3="1178"/>
<product name="SUS 5581 NF Leg 3x3 1" scr1="1280" scr2="1382" scr3="1484"/>
<product name="SUS 5581 NF Leg 3x3 1" scr1="1586" scr2="1688" scr3="1790"/>
</manufacturer>
<manufacturer name="Technisat">
<product name="MiniRouter 2/1x2" scr1="1284" scr2="1400"/>
<product name="TechniRouter 5/1x4" scr1="1210 scr2="1420" scr3="1680" scr4="2040"/>
<product name="TechniRouter 5/1x8" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="TechniRouter 9/1x8" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="TechniRouter 5/2x4" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="TechniRouter 9/2x4" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
</manufacturer>
<manufacturer name="Telstar">
<product name="SCR 5/1x8" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="SCR 9/1x8" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="SCR 5/2x4" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="SCR 9/2x4" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
</manufacturer>
<manufacturer name="Wisi">
<product name="DY 64 1810" scr1="1178" scr2="1280" scr3="1382" scr4="1484" scr5="1586" scr6="1688" scr7="1790" scr8="1892"/>
<product name="DY 64 2410" scr1="1178" scr2="1280" scr3="1382" scr4="1484"/>
<product name="DY 68 1810" positions="2" scr1="1178" scr2="1280" scr3="1382" scr4="1484" scr5="1586" scr6="1688" scr7="1790" scr8="1892"/>
<product name="DY 68 2410" positions="2" scr1="1178" scr2="1280" scr3="1382" scr4="1484"/>
</manufacturer>
</matrix>
</unicable>
Dateianhänge
unicable.rar
unicable.xml für Enigma² Geräte (VU+/ DMM/GigaBlue/Xtrend/Opticum/Clarke-Tech etc)
jetzt für Unicable (EN50494) + JESS (EN5067)
(1.76 KiB) 174-mal heruntergeladen
Vielleicht sind wir nicht günstiger als ein Discounter oder reiner Online-Kartonschieber, aber sicherlich besser !
Normkonforme Beratung und Bau sind bei uns selbstverständlich.
Sat-Shop Heilbronn Kunden können sich auch nach dem Kauf auf unseren besten Service verlassen
Hier im Forum wird kein After-Sales-Support für Fremdkäufe geleistet !! Wenden Sie sich dazu an ihren Verkäufer ......

Tristan Uhde / Satanlagen Onlineshop / SAT-Shop Heilbronn
https://www.satshop-heilbronn.de (SSL) / SAT-Onlineforum https://www.satanlagenforum.de (SSL)
Tel ------ (Fragen gehören ins Forum ! Den nur hier können sie richtig bearbeitet werden, auch was hier noch nicht von A-Z genau schon erklärt/behandelt ist ) .. Dieser Hinweis weil täglich dutzende Fragen per Email oder per PM über das Forum rein kommen die noch dazu inhaltlich nicht das intus haben das man etwas dazu sagen könnte.

Wichtiger Hinweis: Zuständigkeiten verantwortliche Elektrofachkraft (VEFK) und Blitzschutzfachkräfte
Informieren Sie sich dort über Folgen und Auswirkungen von Eigenleistung und lassen Sie selbst durchgeführte Installationen von entsprechender Stelle prüfen und abnehmen. Dafür sind VOR ORT spezielle und qualifizierte Blitzschutz-Fachkräfte notwendig, Ferndiagnosen für Blitzschutz/Erdung können hier NICHT durchgeführt werden ("wie kann ICH das machen ..." oder ähnlich bringt da nichts).

Diese Signatur wächst von Woche zu Woche und enthält immer mehr grundlegende Inhalte die bitte berücksichtigt werden sollten bei bzw. VOR Anfragen !
100% beantwortet werden können nur Anfragen die auch alle relevanten Teile beinhalten die man benötigt für eine Antwort (genaue Beschreibungen/ Angabe von Herstellern/Typen für vorhandenes Material etc.). Bitte vermeiden Sie Aussagen wie "habe viel gelesen, aber ..." ohne Nennung von dem was Sie gelesen haben - den nur dann kann man auch darauf eingehen was event. unklar ist/war.

Bitte unbedingt vor einem Post lesen => Boardregeln / Datenschutz
Wir erteilen hier keine Rechtsberatung, unsere Hinweise sind nach bestem Wissen und bedürfen einer entsprechenden juristischen/technischen weiteren Beratung.

jeezbee
Neuling
Beiträge: 1
Registriert: 29. Dezember 2015 16:54

Re: unicable.xml Enigma² Geräte (VU+/ DMM/GigaBlue/Xtrend etc)

Ungelesener Beitragvon jeezbee » 1. Januar 2016 12:05

Hallo in die Runde,
kann ich die unicable.xml auch bei oe2.0 images einfach überschreiben oder muss das image noch anders bearbeitet werden?
herzlichen dank und ein frohes neues jahr.

Stefan

Benutzeravatar
techno-com
Site Admin
Beiträge: 19741
Registriert: 17. November 2005 09:32
Wohnort: 74076 Heilbronn
Hat sich bedankt: 413 Mal
Danksagung erhalten: 479 Mal
Kontaktdaten:

Re: unicable.xml Enigma² Geräte (VU+/ DMM/GigaBlue/Xtrend etc)

Ungelesener Beitragvon techno-com » 1. Januar 2016 12:21

Diese Frage würde ich an das Image Team stellen....


Beitrag erstellt via Tapatalk
Vielleicht sind wir nicht günstiger als ein Discounter oder reiner Online-Kartonschieber, aber sicherlich besser !
Normkonforme Beratung und Bau sind bei uns selbstverständlich.
Sat-Shop Heilbronn Kunden können sich auch nach dem Kauf auf unseren besten Service verlassen
Hier im Forum wird kein After-Sales-Support für Fremdkäufe geleistet !! Wenden Sie sich dazu an ihren Verkäufer ......

Tristan Uhde / Satanlagen Onlineshop / SAT-Shop Heilbronn
https://www.satshop-heilbronn.de (SSL) / SAT-Onlineforum https://www.satanlagenforum.de (SSL)
Tel ------ (Fragen gehören ins Forum ! Den nur hier können sie richtig bearbeitet werden, auch was hier noch nicht von A-Z genau schon erklärt/behandelt ist ) .. Dieser Hinweis weil täglich dutzende Fragen per Email oder per PM über das Forum rein kommen die noch dazu inhaltlich nicht das intus haben das man etwas dazu sagen könnte.

Wichtiger Hinweis: Zuständigkeiten verantwortliche Elektrofachkraft (VEFK) und Blitzschutzfachkräfte
Informieren Sie sich dort über Folgen und Auswirkungen von Eigenleistung und lassen Sie selbst durchgeführte Installationen von entsprechender Stelle prüfen und abnehmen. Dafür sind VOR ORT spezielle und qualifizierte Blitzschutz-Fachkräfte notwendig, Ferndiagnosen für Blitzschutz/Erdung können hier NICHT durchgeführt werden ("wie kann ICH das machen ..." oder ähnlich bringt da nichts).

Diese Signatur wächst von Woche zu Woche und enthält immer mehr grundlegende Inhalte die bitte berücksichtigt werden sollten bei bzw. VOR Anfragen !
100% beantwortet werden können nur Anfragen die auch alle relevanten Teile beinhalten die man benötigt für eine Antwort (genaue Beschreibungen/ Angabe von Herstellern/Typen für vorhandenes Material etc.). Bitte vermeiden Sie Aussagen wie "habe viel gelesen, aber ..." ohne Nennung von dem was Sie gelesen haben - den nur dann kann man auch darauf eingehen was event. unklar ist/war.

Bitte unbedingt vor einem Post lesen => Boardregeln / Datenschutz
Wir erteilen hier keine Rechtsberatung, unsere Hinweise sind nach bestem Wissen und bedürfen einer entsprechenden juristischen/technischen weiteren Beratung.

geo_f
Neuling
Beiträge: 3
Registriert: 5. Mai 2019 08:43

Re: unicable.xml Enigma² Geräte (VU+/ DMM/GigaBlue/Xtrend etc)

Ungelesener Beitragvon geo_f » 5. Mai 2019 08:47

gibt es die Möglichkeit die Dur-Line UKS 246 als Matrix in die Unicable.xml einzufügen ?
Wenn Ja, wie soll das aussehen ?

Vielen Dank

Benutzeravatar
Wirus
Foren-As
Beiträge: 160
Registriert: 2. Mai 2017 19:46
Danksagung erhalten: 14 Mal

Re: unicable.xml Enigma² Geräte (VU+/ DMM/GigaBlue/Xtrend etc)

Ungelesener Beitragvon Wirus » 5. Mai 2019 10:30

Erst mal willkommen im Forum herlich-willkommen

Das Ganze könnte wie folgt aussehen und muss in die unicable.xml eingefügt werden:

Code: Alles auswählen

- <manufacturer name="Dura-Sat(DUR-line)">
  [...alle andern DUR-Line-Geräte...]
  <product name="UKS 246 Ausgang 1" scr1="1005" scr2="1210" scr3="1420" scr4="1610" scr5="1815" scr6="1995" />
  <product name="UKS 246 Ausgang 2" scr1="1050" scr2="1260" scr3="1475" scr4="1680" scr5="1725" scr6="2040" />
  <product name="UKS 246 Ausgang 3" scr1="1095" scr2="1305" scr3="1520" scr4="1725" scr5="1905" scr6="2085" />
  <product name="UKS 246 Ausgang 4" scr1="1140" scr2="1350" scr3="1565" scr4="1770" scr5="1950" scr6="2130" />
  </manufacturer>


Da die vier Ausgänge von den Frewquenzen her unterschiedlich belegt sind, geht das mit einer Zeile nicht.

Gruß
Werner

geo_f
Neuling
Beiträge: 3
Registriert: 5. Mai 2019 08:43

Re: unicable.xml Enigma² Geräte (VU+/ DMM/GigaBlue/Xtrend etc)

Ungelesener Beitragvon geo_f » 5. Mai 2019 10:54

Vielen Dank. :thx :thx :thx

Soooo siehts schon besser aus.

Hatte selber bereits die unicable.xml geändert, aber die SCR´s falsch angegeben für die 4 Ausgänge.

coolthumb

Benutzeravatar
techno-com
Site Admin
Beiträge: 19741
Registriert: 17. November 2005 09:32
Wohnort: 74076 Heilbronn
Hat sich bedankt: 413 Mal
Danksagung erhalten: 479 Mal
Kontaktdaten:

Re: unicable.xml Enigma² Geräte (VU+/ DMM/GigaBlue/Xtrend etc)

Ungelesener Beitragvon techno-com » 6. Mai 2019 10:10

Genau genommen müsste das so aussehen:
<manufacturer name="Dura-Sat">
<product name="UCP2" scr1="1400" scr2="1516"/>
<product name="UCP3" scr1="1280" scr2="1382" scr3="1484"/>
<product name="UCP20" scr1="1210" scr2="1420"/>
<product name="UCP20 V2" scr1="1284" scr2="1400"/>
<product name="UCP30" scr1="1210" scr2="1420" scr3="1680"/>
<product name="UCP30 V2" scr1="1284" scr2="1400" scr3="1516"/>
<product name="DCR 5-1-8" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790" scr7="1892" scr8="1994"/>
<product name="DCR 5-2-4" scr1="1280" scr2="1382" scr3="1484" scr4="1586"/>
<product name="VDU518NT" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="VDU543NT" scr1="1280" scr2="1382" scr3="1484"/>
<product name="VDU563NT" scr1="1280" scr2="1382" scr3="1484"/>
<product name="VDU583NT" scr1="1280" scr2="1382" scr3="1484"/>
<product name="VDU586NT" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="VDU983NT" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="UKS 146 Ausgang 1" scr1="1005" scr2="1210" scr3="1420" scr4="1610" scr5="1815" scr6="1995" />
<product name="UKS 146 Ausgang 2" scr1="1050" scr2="1260" scr3="1475" scr4="1680" scr5="1725" scr6="2040" />
<product name="UKS 146 Ausgang 3" scr1="1095" scr2="1305" scr3="1520" scr4="1725" scr5="1905" scr6="2085" />
<product name="UKS 146 Ausgang 4" scr1="1140" scr2="1350" scr3="1565" scr4="1770" scr5="1950" scr6="2130" />

<product name="UKS 246 Ausgang 1" positions="2" scr1="1005" scr2="1210" scr3="1420" scr4="1610" scr5="1815" scr6="1995" />
<product name="UKS 246 Ausgang 2" positions="2" scr1="1050" scr2="1260" scr3="1475" scr4="1680" scr5="1725" scr6="2040" />
<product name="UKS 246 Ausgang 3" positions="2" scr1="1095" scr2="1305" scr3="1520" scr4="1725" scr5="1905" scr6="2085" />
<product name="UKS 246 Ausgang 4" positions="2" scr1="1140" scr2="1350" scr3="1565" scr4="1770" scr5="1950" scr6="2130" />
<product name="UCP18" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
</manufacturer>


1. Hersteller-Name sollte genau gleich bleiben, sonst wird der 2x angelegt
2. UKS 246 ist für 2 Sat-Systeme, daher muss der Eintrag - positions="2" - dazu
3. habe ich auch noch das UKW 146 und die Version 2 (V2) Systeme der UCP20/30 gleich mit aufgenommen

Fehlen jetzt noch die DCR-Geräte, aber das sollte recht einfach sein bei denen :1128
Vielleicht sind wir nicht günstiger als ein Discounter oder reiner Online-Kartonschieber, aber sicherlich besser !
Normkonforme Beratung und Bau sind bei uns selbstverständlich.
Sat-Shop Heilbronn Kunden können sich auch nach dem Kauf auf unseren besten Service verlassen
Hier im Forum wird kein After-Sales-Support für Fremdkäufe geleistet !! Wenden Sie sich dazu an ihren Verkäufer ......

Tristan Uhde / Satanlagen Onlineshop / SAT-Shop Heilbronn
https://www.satshop-heilbronn.de (SSL) / SAT-Onlineforum https://www.satanlagenforum.de (SSL)
Tel ------ (Fragen gehören ins Forum ! Den nur hier können sie richtig bearbeitet werden, auch was hier noch nicht von A-Z genau schon erklärt/behandelt ist ) .. Dieser Hinweis weil täglich dutzende Fragen per Email oder per PM über das Forum rein kommen die noch dazu inhaltlich nicht das intus haben das man etwas dazu sagen könnte.

Wichtiger Hinweis: Zuständigkeiten verantwortliche Elektrofachkraft (VEFK) und Blitzschutzfachkräfte
Informieren Sie sich dort über Folgen und Auswirkungen von Eigenleistung und lassen Sie selbst durchgeführte Installationen von entsprechender Stelle prüfen und abnehmen. Dafür sind VOR ORT spezielle und qualifizierte Blitzschutz-Fachkräfte notwendig, Ferndiagnosen für Blitzschutz/Erdung können hier NICHT durchgeführt werden ("wie kann ICH das machen ..." oder ähnlich bringt da nichts).

Diese Signatur wächst von Woche zu Woche und enthält immer mehr grundlegende Inhalte die bitte berücksichtigt werden sollten bei bzw. VOR Anfragen !
100% beantwortet werden können nur Anfragen die auch alle relevanten Teile beinhalten die man benötigt für eine Antwort (genaue Beschreibungen/ Angabe von Herstellern/Typen für vorhandenes Material etc.). Bitte vermeiden Sie Aussagen wie "habe viel gelesen, aber ..." ohne Nennung von dem was Sie gelesen haben - den nur dann kann man auch darauf eingehen was event. unklar ist/war.

Bitte unbedingt vor einem Post lesen => Boardregeln / Datenschutz
Wir erteilen hier keine Rechtsberatung, unsere Hinweise sind nach bestem Wissen und bedürfen einer entsprechenden juristischen/technischen weiteren Beratung.

Benutzeravatar
techno-com
Site Admin
Beiträge: 19741
Registriert: 17. November 2005 09:32
Wohnort: 74076 Heilbronn
Hat sich bedankt: 413 Mal
Danksagung erhalten: 479 Mal
Kontaktdaten:

Re: unicable.xml Enigma² Geräte (VU+/ DMM/GigaBlue/Xtrend etc)

Ungelesener Beitragvon techno-com » 17. Oktober 2019 10:58

Update

Opticum Red Robust Unicable 8-fach LNB eingefügt ( Opticum RED Robust Unicable LNB 8x Unicable + 2x Legacy- Ausgang (Einkabel-LNB / EN50494) ) + kleinere Änderungen/Korrekturen

OPTICUM Red Robust Unicable-LNB 8-fach
ID1 (SCR0): 1210 MHz
ID2 (SCR1): 1420 MHz
ID3 (SCR2): 1680 MHz
ID4 (SCR3): 2040 MHz
ID5 (SCR4): 970 MHz
ID6 (SCR5): 1030 MHz
ID7 (SCR6): 1090 MHz
ID8 (SCR7): 1150 MHz


<?xml version="1.0" encoding="iso-8859-1"?>
<unicable version="20191017">
<!--
structur of tree
unicable (version)
|
|\
| \
| lnb
| |
| |\
| | \
| | manufacturer (name)
| | |\
| | | \
| | | product (name, position, format, scr1-scr32, lofl, lofh, loft)
| | |
| | |\
| | | \
| | | product
| |
| |\
| | \
| | manufacturer
| | |\
| | | \
| | | product
| | |
| | |\
| | | \
| | | product
|
\
\
matrix
|
|\
| \
| manufacturer
| |\
| | \
| | product
| |
| |\
| | \
| | product
|
|\
| \
| manufacturer
| |\
| | \
| | product
| |
| |\
| | \
| | product

-->

<lnb>
<manufacturer name="Dura-Sat (DUR-line)">
<product name="UK101" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="UK102" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="UK 119" format="JESS" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790" scr9="0975" scr10="1025" scr11="1225" scr12="1330" scr13="1430" scr14="1535" scr15="1630" scr16="1730" scr17="1840" scr18="1880" scr19="1920" scr20="1960" scr21="2000" scr22="2040" scr23="2080" scr24="2125" />
<product name="UK 124" format="JESS" scr1="1210" scr2="1420" scr3="1680" scr4="2040" scr5="1005" scr6="1050" scr7="1095" scr8="1140" scr9="1260" scr10="1305" scr11="1350" scr12="1475" scr13="1520" scr14="1565" scr15="1610" scr16="1725" scr17="1770" scr18="1815" scr19="1860" scr20="1905" scr21="1950" scr22="1995" scr23="2085" scr24="2130" />
</manufacturer>
<manufacturer name="EDISON">
<product name="SCR-1" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
<manufacturer name="Fuba">
<product name="DEK 342" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
<manufacturer name="G-STAR">
<product name="GS-404-L1" scr1="1280" scr2="1382" scr3="1484"/>
<product name="GS-406-L1" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
</manufacturer>
<manufacturer name="GT-SAT">
<product name="GT-S1-2-3SCR4" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="dLNB dHello" format="EN50607"
scr1="0975" scr2="1025" scr3="1075" scr4="1125" scr5="1175" scr6="1225" scr7="1275" scr8="1325"
scr9="1375" scr10="1425" scr11="1475" scr12="1525" scr13="1575" scr14="1625" scr15="1675" scr16="1725"
scr17="1775" scr18="1825" scr19="1875" scr20="1925" scr21="1975" scr22="2025" scr23="2075" scr24="2125"/>
<product name="GT S3dCSS24" format="EN50607"
scr1="0975" scr2="1025" scr3="1075" scr4="1125" scr5="1175" scr6="1225" scr7="1275" scr8="1325"
scr9="1375" scr10="1425" scr11="1475" scr12="1525" scr13="1575" scr14="1625" scr15="1675" scr16="1725"
scr17="1775" scr18="1825" scr19="1875" scr20="1925" scr21="1975" scr22="2025" scr23="2075" scr24="2125"/>
</manufacturer>
<manufacturer name="Humax">
<product name="150 SCR" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
<manufacturer name="Inverto">
<product name="IDLP-40UNIQD+S" scr1="1680" scr2="1420" scr3="2040" scr4="1210"/>
<product name="IDLB-QUDL-UNI2L-OPP" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="IDLB-QUDL42-UNI2L-1PP" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="IDLU-24UL40-UNMOO-OPP" format="JESS" scr1="1210" scr2="1420" scr3="1680" scr4="2040" scr5="1005" scr6="1050" scr7="1095" scr8="1140" scr9="1260" scr10="1305" scr11="1350" scr12="1475" scr13="1520" scr14="1565" scr15="1610" scr16="1725" scr17="1770" scr18="1815" scr19="1860" scr20="1905" scr21="1950" scr22="1995" scr23="2085" scr24="2130" />
<product name="IDLU-32UL40-UNBOO-OPP" format="JESS" scr1="1210" scr2="1420" scr3="1680" scr4="2040" scr5="984" scr6="1020" scr7="1056" scr8="1092" scr9="1128" scr10="1164" scr11="1256" scr12="1292" scr13="1328" scr14="1364" scr15="1458" scr16="1494" scr17="1530" scr18="1566" scr19="1602" scr20="1638" scr21="1716" scr22="1752" scr23="1788" scr24="1824" scr25="1860" scr26="1896" scr27="1932" scr28="1968" scr29="2004" scr30="2076" scr31="2112" scr32="2148" />
</manufacturer>
<manufacturer name="Kathrein">
<product name="UAS481" lofl="10200" lofh="10200" scr1="1400" scr2="1516" scr3="1632" scr4="1748"/>
</manufacturer>
<manufacturer name="Kreiling">
<product name="KR1440" scr1="1680" scr2="1420" scr3="2040" scr4="1210"/>
</manufacturer>
<manufacturer name="Opticum">
<product name="RED Robusta 8" scr1="1210" scr2="1420" scr3="1680" scr4="2040" scr5="0970" scr6="1030" scr7="1090" scr8="1150"/>
</manufacturer>
<manufacturer name="Radix">
<product name="Unicable LNB" scr1="1680" scr2="1420" scr3="2040" scr4="1210"/>
</manufacturer>
<manufacturer name="SelfSat">
<product name="H21dCSS" format="JESS" scr1="1210" scr2="1420" scr3="1680" scr4="2040" scr5="1005" scr6="1050" scr7="1095" scr8="1140" scr9="1260" scr10="1305" scr11="1350" scr12="1475" scr13="1520" scr14="1565" scr15="1610" scr16="1725" scr17="1770" scr18="1815" scr19="1860" scr20="1905" scr21="1950" scr22="1995" scr23="2085" scr24="2130" />
</manufacturer>
<manufacturer name="Sharp">
<product name="BS1R8EL600A" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
<manufacturer name="Schwaiger">
<product name="SPS6941 531" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
<manufacturer name="Telestar">
<product name="Skywire HC LNB" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="Skywire 2HC LNB" format="JESS" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790" scr9="975" scr10="1025" scr11="1225" scr12="1330" scr13="1430" scr14="1535" scr15="1630" scr16="1730" scr17="1840" scr18="1880" scr19="1920" scr20="1960" scr21="2000" scr22="2040" scr23="2080" scr24="2125" />
</manufacturer>
<manufacturer name="Triax">
<product name="TSC 001" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
<manufacturer name="Wisi">
<product name="OC 05" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
</manufacturer>
</lnb>
<matrix>
<manufacturer name="Ankaro">
<product name="UCS 51440" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 51820" scr1="1400" scr2="1632" scr3="1284" scr4="1516" scr5="1864" scr6="2096" scr7="1748" scr8="1980"/>
<product name="UCS 51840" scr1="1400" scr2="1632" scr3="1284" scr4="1516" scr5="1864" scr6="2096" scr7="1748" scr8="1980"/>
<product name="UCS 52240" scr1="1400" scr2="1632"/>
<product name="UCS 52420" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 52440" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 91440" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 91820" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516" scr5="1864" scr6="2096" scr7="1748" scr8="1980"/>
<product name="UCS 91840" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516" scr5="1864" scr6="2096" scr7="1748" scr8="1980"/>
<product name="UCS 92240" positions="2" scr1="1400" scr2="1632"/>
<product name="UCS 92420" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
<product name="UCS 92440" positions="2" scr1="1400" scr2="1632" scr3="1284" scr4="1516"/>
</manufacturer>
<manufacturer name="Astra Strobel">
<product name="SEV 103" format="EN50494" positions="1" scr1="1284" scr2="1400" scr3="1514"/>
<product name="SEV 108" format="EN50494" positions="1" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="SEV 208" format="EN50494" positions="2" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
</manufacturer>
<manufacturer name="Axing">
<product name="SES 556-19" format="EN50494" positions="1" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="SES 556-09" format="EN50494" positions="1" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="SES 996-19" format="EN50494" positions="2" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="SES 996-09" format="EN50494" positions="2" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="SES 46-00" format="EN50494" positions="1" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="SES 86-00" format="EN50494" positions="2" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
</manufacturer>
<manufacturer name="DCT Delta">
<product name="SUM518" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096" alias1="SCR0" alias2="SCR1" alias3="SCR2" alias4="SCR3" alias5="SCR4" alias6="SCR5" alias7="SCR6" alias8="SCR7"/>
<product name="SUM918" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="SUM928" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
</manufacturer>
<manufacturer name="Dura-Sat (Dur-Line)">
<product name="DPC/DWB-32 K" format="JESS" positions="2" scr1="1210" scr2="1420" scr3="1680" scr4="2040" scr5="984" scr6="1020" scr7="1056" scr8="1092" scr9="1128" scr10="1164" scr11="1256" scr12="1292" scr13="1328" scr14="1364" scr15="1458" scr16="1494" scr17="1530" scr18="1566" scr19="1602" scr20="1638" scr21="1716" scr22="1752" scr23="1788" scr24="1824" scr25="1860" scr26="1896" scr27="1932" scr28="1968" scr29="2004" scr30="2076" scr31="2112" scr32="2148"/>
<product name="DCR 5-1-8 V2(L4/K)" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790" scr7="1892" scr8="1994"/>
<product name="DCR 5-2-4 V2 (L4/K)" scr1="1280" scr2="1382" scr3="1484" scr4="1586"/>
<product name="UKS 146 Ausgang 1" scr1="1005" scr2="1210" scr3="1420" scr4="1610" scr5="1815" scr6="1995" />
<product name="UKS 146 Ausgang 2" scr1="1050" scr2="1260" scr3="1475" scr4="1680" scr5="1725" scr6="2040" />
<product name="UKS 146 Ausgang 3" scr1="1095" scr2="1305" scr3="1520" scr4="1725" scr5="1905" scr6="2085" />
<product name="UKS 146 Ausgang 4" scr1="1140" scr2="1350" scr3="1565" scr4="1770" scr5="1950" scr6="2130" />
<product name="UKS 246 Ausgang 1" positions="2" scr1="1005" scr2="1210" scr3="1420" scr4="1610" scr5="1815" scr6="1995" />
<product name="UKS 246 Ausgang 2" positions="2" scr1="1050" scr2="1260" scr3="1475" scr4="1680" scr5="1725" scr6="2040" />
<product name="UKS 246 Ausgang 3" positions="2" scr1="1095" scr2="1305" scr3="1520" scr4="1725" scr5="1905" scr6="2085" />
<product name="UKS 246 Ausgang 4" positions="2" scr1="1140" scr2="1350" scr3="1565" scr4="1770" scr5="1950" scr6="2130" />
<product name="UCP18" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="UCP20 V2" scr1="1284" scr2="1400"/>
<product name="UCP30" scr1="1210" scr2="1420" scr3="1680"/>
<product name="UCP30 V2" scr1="1284" scr2="1400" scr3="1516"/>
<product name="UCP2" scr1="1400" scr2="1516"/>
<product name="UCP3" scr1="1280" scr2="1382" scr3="1484"/>
<product name="UCP18" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="UCP20" scr1="1210" scr2="1420"/>
<product name="DCR 5-1-8 V1 (L4/K)" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790" scr7="1892" scr8="1994"/>
<product name="DCR 5-2-4 V1 (L4/K)" scr1="1280" scr2="1382" scr3="1484" scr4="1586"/>
<product name="VDU543NT" scr1="1280" scr2="1382" scr3="1484"/>
<product name="VDU563NT" scr1="1280" scr2="1382" scr3="1484"/>
<product name="VDU583NT" scr1="1280" scr2="1382" scr3="1484"/>
<product name="VDU586NT" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="VDU518NT" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="VDU983NT" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="UCP18" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
</manufacturer>
<manufacturer name="EMP-Centauri">
<product name="MS4/1(6)EUN-3" positions="1" scr1="1400" scr2="1632" scr3="1284" scr4="1516" scr5="1864" scr6="2096"/>
<product name="MS4/1(8)PIN-4" positions="1" scr1="1080" scr2="1176" scr3="1237" scr4="1413" scr5="1555" scr6="1668" scr7="1842" scr8="1960" />
<product name="MS8/1(8)PIN-4" positions="2" scr1="1080" scr2="1176" scr3="1237" scr4="1413" scr5="1555" scr6="1668" scr7="1842" scr8="1960"/>
<product name="MS5/5+2PIP-4" positions="1" scr1="1080" scr2="1176" scr3="1237" scr4="1413" scr5="1555" scr6="1668" scr7="1842" scr8="1960" />
<product name="MS5/5+2PEP-4" positions="1" scr1="1080" scr2="1176" scr3="1237" scr4="1413" scr5="1555" scr6="1668" scr7="1842" scr8="1960" />
</manufacturer>
<manufacturer name="Fuba">
<product name="MCR 212" format="EN50494" positions="1" scr1="1400" scr2="1516"/>
<product name="MCR 221" format="EN50607" positions="1" scr1="1280" scr2="1382"/>
<product name="MCR 441" format="EN50607" positions="1" scr1="1280" scr2="1382" scr3="1484" scr4="1586"/>
<product name="MCR 518" format="EN50494" positions="1" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="MCR 918" format="EN50494" positions="2" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
</manufacturer>
<manufacturer name="G-STAR">
<product name="GS-506-S1" scr1="1280" scr2="1382" scr3="1484"/>
<product name="GS-516-S1" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
</manufacturer>
<manufacturer name="GSS (Grundig SAT-Systems)">
<product name="SDUC 502" positions="1" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="SDUC 902" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
</manufacturer>
<manufacturer name="Inverto">
<product name="IDLP-UST1O1-CUO1O-4PP" format="DiSEqC" positions="1" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="IDLP-UST11O-CUO1O-8PP" format="DiSEqC" positions="1" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="IDLP-UST111-CUO1O-8PP" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="IDLP-UST112-CUO1O-8PP" format="DiSEqC" positions="1" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="IDLP-USS200-CUO10-8PP" format="DiSEqC" positions="2" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="IDLU-UST110-CUO10-32PP" format="JESS" scr1="1210" scr2="1420" scr3="1680" scr4="2040" scr5="984" scr6="1020" scr7="1056" scr8="1092" scr9="1128" scr10="1164" scr11="1256" scr12="1292" scr13="1328" scr14="1364" scr15="1458" scr16="1494" scr17="1530" scr18="1566" scr19="1602" scr20="1638" scr21="1716" scr22="1752" scr23="1788" scr24="1824" scr25="1860" scr26="1896" scr27="1932" scr28="1968" scr29="2004" scr30="2076" scr31="2112" scr32="2148"/>
<product name="IDLU-UWT110-CUO10-32PP" format="JESS" positions="2" scr1="1210" scr2="1420" scr3="1680" scr4="2040" scr5="984" scr6="1020" scr7="1056" scr8="1092" scr9="1128" scr10="1164" scr11="1256" scr12="1292" scr13="1328" scr14="1364" scr15="1458" scr16="1494" scr17="1530" scr18="1566" scr19="1602" scr20="1638" scr21="1716" scr22="1752" scr23="1788" scr24="1824" scr25="1860" scr26="1896" scr27="1932" scr28="1968" scr29="2004" scr30="2076" scr31="2112" scr32="2148"/>
<product name="IDLU-UST110-CUO40-32PP" format="JESS" positions="2" scr1="1210" scr2="1420" scr3="1680" scr4="2040" scr5="985" scr6="1050" scr7="1115" scr8="1275" scr9="1340" scr10="1485" scr11="1550" scr12="1615" scr13="1745" scr14="1810" scr15="1875" scr16="1940" />

</manufacturer>
<manufacturer name="Johansson/Uunitron">
<product name="9712A" format="DiSEqC" positions="1" scr1="1280" scr2="1382" scr3="1484"/>
<product name="9730I" format="DiSEqC" positions="1" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="9740" format="DiSEqC" positions="1" scr1="1280" scr2="1382" scr3="1484"/>
<product name="9740D" format="DiSEqC" positions="1" scr1="1280" scr2="1382" scr3="1484"/>
<product name="9740I" format="DiSEqC" positions="1" scr1="1210" scr2="1420" scr3="1680"/>
<product name="9742" format="DiSEqC" positions="1" scr1="1280" scr2="1382" scr3="1484"/>
<product name="9742D" format="DiSEqC" positions="1" scr1="1280" scr2="1382" scr3="1484"/>
<product name="9742I" format="DiSEqC" positions="1" scr1="1210" scr2="1420" scr3="1680"/>
<product name="9750" format="DiSEqC" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="9750D" format="DiSEqC" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="9750I" format="DiSEqC" positions="2" scr1="1210" scr2="1420" scr3="1680"/>
<product name="9752" format="DiSEqC" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="9752D" format="DiSEqC" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="9752I" format="DiSEqC" positions="2" scr1="1210" scr2="1420" scr3="1680"/>
<product name="9760" format="JESS" positions="4" scr1="1280" scr2="1382" scr3="1484"/>
<product name="9760D" format="JESS" positions="4" scr1="1280" scr2="1382" scr3="1484"/>
<product name="9760I" format="JESS" positions="4" scr1="1210" scr2="1420" scr3="1680"/>
<product name="9762" format="JESS" positions="4" scr1="1280" scr2="1382" scr3="1484"/>
<product name="9762D" format="JESS" positions="4" scr1="1280" scr2="1382" scr3="1484"/>
<product name="9762I" format="JESS" positions="4" scr1="1210" scr2="1420" scr3="1680"/>
</manufacturer>
<manufacturer name="JULTEC">
<product name="a2CSS 1Sat 4UBs" format="JESS" scr1="1375" scr2="1425" scr3="1475" scr4="1525"/>
<product name="a2CSS 1Sat 8UBs" format="JESS" scr1="1375" scr2="1425" scr3="1475" scr4="1525" scr5="1575" scr6="1625" scr7="1675" scr8="1725"/>
<product name="a2CSS 1Sat 16UBs" format="JESS" scr1="1375" scr2="1425" scr3="1475" scr4="1525" scr5="1575" scr6="1625" scr7="1675" scr8="1725" scr9="1775" scr10="1825" scr11="1875" scr12="1925" scr13="1975" scr14="2025" scr15="2075" scr16="2125"/>
<product name="a2CSS 2Sat 4UBs" positions="2" format="JESS" scr1="1375" scr2="1425" scr3="1475" scr4="1525"/>
<product name="a2CSS 2Sat 8UBs" positions="2" format="JESS" scr1="1375" scr2="1425" scr3="1475" scr4="1525" scr5="1575" scr6="1625" scr7="1675" scr8="1725"/>
<product name="a2CSS 2Sat 16UBs" positions="2" format="JESS" scr1="1375" scr2="1425" scr3="1475" scr4="1525" scr5="1575" scr6="1625" scr7="1675" scr8="1725" scr9="1775" scr10="1825" scr11="1875" scr12="1925" scr13="1975" scr14="2025" scr15="2075" scr16="2125"/>
<product name="a2CSS 4Sat 4UBs" positions="4" format="JESS" scr1="1375" scr2="1425" scr3="1475" scr4="1525"/>
<product name="a2CSS 4Sat 8UBs" positions="4" format="JESS" scr1="1375" scr2="1425" scr3="1475" scr4="1525" scr5="1575" scr6="1625" scr7="1675" scr8="1725"/>
<product name="a2CSS 4Sat 16UBs" positions="4" format="JESS" scr1="1375" scr2="1425" scr3="1475" scr4="1525" scr5="1575" scr6="1625" scr7="1675" scr8="1725" scr9="1775" scr10="1825" scr11="1875" scr12="1925" scr13="1975" scr14="2025" scr15="2075" scr16="2125"/>
<product name="JPS0501-6" format="JESS" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS0501-8(A/M/T)" format="JESS" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="JPS0501-12(MN/TN)" format="JESS" scr1="974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="JRS0502-2+4" format="JESS" scr1="1280" scr2="1382"/>
<product name="JPS0502-3(A/T)" format="JESS" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0502-6(M/T)" format="JESS" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JRS0504-2" format="JESS" scr1="1280" scr2="1382"/>
<product name="JPS0504-3(A/T)" format="JESS" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0504-6(M/T)" format="JESS" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS0506-3(A/T)" format="JESS" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0508-3(A/M/T)" format="JESS" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0901-6(A/M/T)" positions="2" format="JESS" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS0901-12(AN/TN)" positions="2" format="JESS" scr1="974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="JPS0902-12(MN/TN)" positions="2" format="JESS" scr1="974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="JPS0902-3" positions="2" format="JESS" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0902-6(A/M/T)" positions="2" format="JESS" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS0904-3(A/M/T)" positions="2" format="JESS" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0904-6(M/T)" positions="2" format="JESS" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS0906-3(A/M/T)" positions="2" format="JESS" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS0908-3(A/M/T)" positions="2" format="JESS" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS1701-12(AN/TN)" positions="4" format="JESS" scr1="974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="JPS1702-12(MN/TN)" positions="4" format="JESS" scr1="974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688" scr9="1790" scr10="1892" scr11="1994" scr12="2096"/>
<product name="JPS1702-6(A/M/T)" positions="4" format="JESS" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS1704-3(A/M/T)" positions="4" format="JESS" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS1704-6(M/T)" positions="4" format="JESS" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790"/>
<product name="JPS1706-3(A/M/T)" positions="4" format="JESS" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JPS1708-3(A/M/T)" positions="4" format="JESS" scr1="1280" scr2="1382" scr3="1484"/>
<product name="JRS0502-2+4(T)" positions="1" format="JESS" scr1="1280" scr2="1382"/>
<product name="JRS0504-2(A/T)" positions="1" format="JESS" scr1="1280" scr2="1382"/>
<product name="JRS0902-2+4(T)" positions="2" format="JESS" scr1="1280" scr2="1382"/>
<product name="JRS0904-2(A/T)" positions="2" format="JESS" scr1="1280" scr2="1382"/>
</manufacturer>
<manufacturer name="Kathrein">
<product name="EXR501" scr1="1400" scr2="1516" scr3="1632" scr4="1748"/>
<product name="EXR551" scr1="1400" scr2="1516" scr3="1632" scr4="1748"/>
<product name="EXR552" scr1="1400" scr2="1516"/>
<product name="EXR1541" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR1542" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR1581" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="EXR1942" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR1981" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="EXR2541" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR2542" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR2581" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="EXR2942" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXR2981" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="EXU908" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="EXE 159" format="SCD2" scr1="974" permpin1="151" scr2="1076" permpin2="052" scr3="1178" permpin3="133" scr4="1280" permpin4="124" scr5="1382" permpin5="205" scr6="1484" permpin6="196" scr7="1586" permpin7="187" scr8="1688" permpin8="178" scr9="1790" permpin9="099"/>
<product name="EXE 259" format="SCD2" scr1="974" permpin1="151" scr2="1076" permpin2="052" scr3="1178" permpin3="133" scr4="1280" permpin4="124" scr5="1382" permpin5="205" scr6="1484" permpin6="196" scr7="1586" permpin7="187" scr8="1688" permpin8="178" scr9="1790" permpin9="099"/>
<product name="EXE 1512" format="SCD2" scr1="974" permpin1="151" scr2="1076" permpin2="052" scr3="1178" permpin3="133" scr4="1280" permpin4="124" scr5="1382" permpin5="205" scr6="1484" permpin6="196" scr7="1586" permpin7="187" scr8="1688" permpin8="178" scr9="1790" permpin9="099" scr10="1892" permpin10="232" scr11="1994" permpin11="198" scr12="2096" permpin12="111"/>
<product name="EXE 2512" format="SCD2" scr1="974" permpin1="151" scr2="1076" permpin2="052" scr3="1178" permpin3="133" scr4="1280" permpin4="124" scr5="1382" permpin5="205" scr6="1484" permpin6="196" scr7="1586" permpin7="187" scr8="1688" permpin8="178" scr9="1790" permpin9="099" scr10="1892" permpin10="232" scr11="1994" permpin11="198" scr12="2096" permpin12="111"/>
</manufacturer>
<manufacturer name="Kreiling">
<product name="KR 2-1-2 Uni-D" format="DiSEqC" positions="2" scr1="1400" scr2="1516"/>
<product name="KR 5-1+4" format="DiSEqC" positions="1" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790" scr7="1892" scr8="1994"/>
<product name="KR 5-2+4" format="DiSEqC" positions="1" scr1="1280" scr2="1382" scr3="1484" scr4="1586"/>
<product name="KR 5-5-1-8" format="DiSEqC" positions="1" scr1="1280" scr2="1382" scr3="1484" scr4="1586" scr5="1688" scr6="1790" scr7="1892" scr8="1994"/>
<product name="KR 5-5-2-4" format="DiSEqC" positions="1" scr1="1280" scr2="1382" scr3="1484" scr4="1586"/>
</manufacturer>
<manufacturer name="Rogetech">
<product name="CMS-518C" format="EN50494" positions="1" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
</manufacturer>
<manufacturer name="ROTEK">
<product name="EKL2/1" scr1="1400" scr2="1516"/>
<product name="EKL2/1E" scr3="1632" scr4="1748"/>
</manufacturer>
<manufacturer name="SetOne">
<product name="SCR 5/8" positions="1" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
</manufacturer>
<manufacturer name="Smart">
<product name="DPA 51" format="DiSEqC" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="DPA 524 L" format="JESS" scr1="1280" scr2="1382" scr3="1484" scr4="1586"/>
</manufacturer>
<manufacturer name="Spaun">
<product name="SUS 21 F" format="EN50494" scr1="1076" scr2="1178"/>
<product name="SUS 21 FI" format="EN50494" scr1="1210" scr2="1420"/>
<product name="SUS 4441 F" format="EN50494" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="SUS 5541 F-NFA" format="EN 50494" scr1="0974" scr2="1076" scr3="1178" scr4="1280"/>
<product name="SUS 5581 F-NFA" format="UniSEqC" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688"/>
<product name="SUS 5581 F-NFA" format="UniSEqC" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688"/>
<product name="SUS 5581 F-NFA" format="UniSEqC" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688"/>
<product name="SUS 5581 NF 1x8" format="UniSEqC" scr1="1068" scr2="1284" scr3="1400" scr4="1516" scr5="1632" scr6="1748" scr7="1864" scr8="1980"/>
<product name="SUS 5581 NF 3x3 1" format="UniSEqC" scr1="1068" scr2="1284" scr3="1400"/>
<product name="SUS 5581 NF 3x3 1" format="UniSEqC" scr1="1516" scr2="1632" scr3="1748"/>
<product name="SUS 5581 NF 3x3 1" format="UniSEqC" scr1="1864" scr2="1980" scr3="2096"/>
<product name="SUS 5581 NF Leg 1x8" format="UniSEqC" scr1="0974" scr2="1076" scr3="1178" scr4="1280" scr5="1382" scr6="1484" scr7="1586" scr8="1688"/>
<product name="SUS 5581 NF Leg 3x3 1" format="UniSEqC" scr1="0974" scr2="1076" scr3="1178"/>
<product name="SUS 5581 NF Leg 3x3 1" format="UniSEqC" scr1="1280" scr2="1382" scr3="1484"/>
<product name="SUS 5581 NF Leg 3x3 1" format="UniSEqC" scr1="1586" scr2="1688" scr3="1790"/>
<product name="SUS 41 F" positions="4" format="JESS" scr1="1076" scr2="1178" scr3="1280" scr4="1382"/>
<product name="SUS 41 F2" positions="4" format="DiSEqC" scr1="1076" scr2="1178" scr3="1280" scr4="1382"/>
<product name="SUS 41 F3" positions="4" format="EN50607" scr1="1076" scr2="1178" scr3="1280" scr4="1382"/>
<product name="SUS 9942/8 NF Leg 2x4" positions="2" format="UniSEqC" scr1="1076" scr2="1178" scr3="1280" scr4="1382"/>
</manufacturer>
<manufacturer name="Technisat">
<product name="TechniRouter Mini 2/1x2" format="EN50494" positions="2" scr1="1284" scr2="1400" permpin1="111" permpin2="222"/>
<product name="TechniRouter 5/1x4" scr1="1210" scr2="1420" scr3="1680" scr4="2040"/>
<product name="TechniRouter 5/1x8" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="TechniRouter 9/1x8" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="TechniRouter 5/2x4" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="TechniRouter 9/2x4" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="TechniRouter 5/2x16" format="EN50607" positions="2"
scr1 ="1210" scr2 ="1420" scr3 ="1680" scr4 ="2040" scr5 ="985" scr6 ="1050" scr7 ="1115" scr8 ="1275"
scr9 ="1340" scr10="1485" scr11="1550" scr12="1615" scr13="1745" scr14="1810" scr15="1875" scr16="1940"/>
</manufacturer>
<manufacturer name="Telestar">
<product name="SCR 5/1x8" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="SCR 9/1x8" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632" scr5="1748" scr6="1864" scr7="1980" scr8="2096"/>
<product name="SCR 5/2x4" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
<product name="SCR 9/2x4" positions="2" scr1="1284" scr2="1400" scr3="1516" scr4="1632"/>
</manufacturer>
<manufacturer name="Triax">
<product name="TUM 518" format="EN50494" positions="1" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="TUM 918" format="EN50494" positions="2" scr1="1076" scr2="1178" scr3="1280" scr4="1382" scr5="1484" scr6="1586" scr7="1688" scr8="1790"/>
<product name="TUM 543C" format="EN50607" positions="1" scr1="1280" scr2="1382" scr3="1484"/>
<product name="TUM 583C" format="EN50607" positions="1" scr1="1280" scr2="1382" scr3="1484"/>
<product name="TUM 943C" format="EN50607" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="TUM 983C" format="EN50607" positions="2" scr1="1280" scr2="1382" scr3="1484"/>
<product name="TUM 1743C" format="EN50607" positions="4" scr1="1280" scr2="1382" scr3="1484"/>
<product name="TUM 1783C" format="EN50607" positions="4" scr1="1280" scr2="1382" scr3="1484"/>
</manufacturer>
<manufacturer name="Wisi">
<product name="DY 64 1800" scr1="1178" scr2="1280" scr3="1382" scr4="1484" scr5="1586" scr6="1688" scr7="1790" scr8="1892"/>
<product name="DY 64 1810" scr1="1178" scr2="1280" scr3="1382" scr4="1484" scr5="1586" scr6="1688" scr7="1790" scr8="1892"/>
<product name="DY 64 2400" scr1="1178" scr2="1280" scr3="1382" scr4="1484"/>
<product name="DY 64 2410" scr1="1178" scr2="1280" scr3="1382" scr4="1484"/>
<product name="DY 68 1810" positions="2" scr1="1178" scr2="1280" scr3="1382" scr4="1484" scr5="1586" scr6="1688" scr7="1790" scr8="1892"/>
<product name="DY 68 2410" positions="2" scr1="1178" scr2="1280" scr3="1382" scr4="1484"/>
</manufacturer>
</matrix>
</unicable>
Dateianhänge
unicable.rar
unicable.xml für Enigma² Geräte (VU+/ DMM/GigaBlue/Xtrend/Opticum/Clarke-Tech/Anadol etc)
jetzt für Unicable (EN50494) + JESS (EN5067)
(3.38 KiB) 21-mal heruntergeladen
Vielleicht sind wir nicht günstiger als ein Discounter oder reiner Online-Kartonschieber, aber sicherlich besser !
Normkonforme Beratung und Bau sind bei uns selbstverständlich.
Sat-Shop Heilbronn Kunden können sich auch nach dem Kauf auf unseren besten Service verlassen
Hier im Forum wird kein After-Sales-Support für Fremdkäufe geleistet !! Wenden Sie sich dazu an ihren Verkäufer ......

Tristan Uhde / Satanlagen Onlineshop / SAT-Shop Heilbronn
https://www.satshop-heilbronn.de (SSL) / SAT-Onlineforum https://www.satanlagenforum.de (SSL)
Tel ------ (Fragen gehören ins Forum ! Den nur hier können sie richtig bearbeitet werden, auch was hier noch nicht von A-Z genau schon erklärt/behandelt ist ) .. Dieser Hinweis weil täglich dutzende Fragen per Email oder per PM über das Forum rein kommen die noch dazu inhaltlich nicht das intus haben das man etwas dazu sagen könnte.

Wichtiger Hinweis: Zuständigkeiten verantwortliche Elektrofachkraft (VEFK) und Blitzschutzfachkräfte
Informieren Sie sich dort über Folgen und Auswirkungen von Eigenleistung und lassen Sie selbst durchgeführte Installationen von entsprechender Stelle prüfen und abnehmen. Dafür sind VOR ORT spezielle und qualifizierte Blitzschutz-Fachkräfte notwendig, Ferndiagnosen für Blitzschutz/Erdung können hier NICHT durchgeführt werden ("wie kann ICH das machen ..." oder ähnlich bringt da nichts).

Diese Signatur wächst von Woche zu Woche und enthält immer mehr grundlegende Inhalte die bitte berücksichtigt werden sollten bei bzw. VOR Anfragen !
100% beantwortet werden können nur Anfragen die auch alle relevanten Teile beinhalten die man benötigt für eine Antwort (genaue Beschreibungen/ Angabe von Herstellern/Typen für vorhandenes Material etc.). Bitte vermeiden Sie Aussagen wie "habe viel gelesen, aber ..." ohne Nennung von dem was Sie gelesen haben - den nur dann kann man auch darauf eingehen was event. unklar ist/war.

Bitte unbedingt vor einem Post lesen => Boardregeln / Datenschutz
Wir erteilen hier keine Rechtsberatung, unsere Hinweise sind nach bestem Wissen und bedürfen einer entsprechenden juristischen/technischen weiteren Beratung.

geo_f
Neuling
Beiträge: 3
Registriert: 5. Mai 2019 08:43

Re: unicable.xml Enigma² Geräte (VU+/ DMM/GigaBlue/Xtrend etc)

Ungelesener Beitragvon geo_f » 8. Januar 2020 18:10

Super machst du das Tristan

:thx


Zurück zu „VU+“
